Revolving Doors

   CL Classic        CL Classic Large       LF Light Frame       FG Full Glass

Where external wind or adverse environmental conditions exist, Byrnes Entrance Technology (BET) revolving doors are the ideal choice. In addition to this BET revolving door systems provide an elegant appearance - yet inside they contribute to providing an effective barrier against draught, heat loss, dirt and noise filtration.

BET revolving doors invite persons to enter. This is a draught proof system that is particularly suitable for high pedestrian traffic applications where maximum user convenience is required - such as airport terminal buildings, hospitals, shopping complexes and major office buildings. BET revolving doors are available in an attractive range of architectural finishes - aluminium anodised or powder coated, stainless steel No 4 satin finish or No 8 mirror finish or classical brass.

The drive motor can be located in the canopy or below the floor where height is restricted. Options available are: manual or automatic operation revolving ceilings, curved lockable side lights for security after hours and panic breakout doors for emergency egress.

BET revolving doors are also ideal for security applications where restricted access is required to allow the passage of authorised persons only. In this application each segment is monitored so that the revolving door can be designed to reverse if an unauthorised person enters the revolving door.

Models available include:

Model: CL Classic
The revolving door to be 1800/2200/2400/2600/2800/3000/3200/3600/4000mm overall diameter x 2100/3000 door wing height x 400 canopy height x 2500/3400 overall height, comprising of three/four door wings, complete with BET drive system incorporated into the canopy and electronic controller.

Model: CL Classic Large (widebody)
The revolving door to be 3600/4000/4400/4800/6200mm overall diameter x 2100/3000 door wing height x 500 canopy height x 2600/3500 overall height, comprising of three/four door wings, complete with BET drive system incorporated into the canopy and electronic controller.

Model: LF Light Frame (with glass canopy)
The revolving door to be 1800/2200/2400/2600/2800/3000mm overall diameter x 2100/3000 door wing height x 60 glass canopy height x 2160/3060 overall height, comprising of three/four door wings, complete with BET drive system incorporated into the canopy and electronic controller.

Model: FG Full Glass (with glass canopy)
The revolving door to be 1800/2200/2400/2600/2800/3000mm overall diameter x 2100/3000 door wing height x 60 glass canopy height x 2160/3060 overall height, comprising of three/four door wings, complete with BET drive system incorporated into the canopy and electronic controller.
